Product Description
Product Description
Product Specification
| Model | ZGRB-06-2000-012-W-MK | | Performance | Installation method | Ground, hoisting, wall | | Freedom of movement | 6-axis | | Payload | 12 kg | | Maximum reach | 2000 mm | | Repeat positioning accuracy | 0.05 mm | | Self weight | 313kg | | Temperature | 0-45°C | | Humidity | 20%-80% | | Power capacity | 4.5 KVA | | Max. Working Range Swivel | J1 | ± 160º | | J2 | -55º ~ +170º | | J3 | -75º ~ +145º | | J4 | ± 190º | | J5 | ± 130º | | J6 | ± 220º | | Max. Speed | J1 | 179º/s | | J2 | 179º/s | | J3 | 162º/s | | J4 | 315º/s | | J5 | 276º/s | | J6 | 1356º/s | | Allowable Moment Bending | J4 | 103.5Nm | | J5 | 51.84Nm | | J6 | 32.64Nm |
|
Product Specification
It is widely used in Automotive Industry, Aerospace Industry,
Railway Industry, Metal Fabrication,Shipbuilding,
Construction,Oil and Gas Industry,Heavy Machinery Manufacturing,
etc.
AIDA is a high-tech enterprise integrating R&D, production and
service, as a solution provider of professional material
handling equipment and flexible intralogistics system for all
scenarios.
Offer products including series of
electric pallet truck, electric stacker and a series of hand pallet
truck, semi electric
stacker and reach stacker and other material handling equipment. Widely used in logistics and warehousing, retail
and wholesale, medicine, food, chemical, electronics, machinery,
automobile and other industries.
AIDA have established a strict quality assurance system and
have passed ISO9001,ISO14001,SGS,and CE certification.
It is a national high-tech enterprise with more than 40 national
patents, which has been rated as "Small giant enterprise in
Hunan Province", "The first batch of pilot enterprises for the
integration of advanced manufacturing and modern service
industries in Hunan Province","Demonstration enterprise of
intelligent manufacturing in Changsha City"," Hunan Enterprise
Technology Center".
"Energy saving, environmental protection, high efficiency and
intelligence" is the design concept of AIDA products, and it is
committed to becoming a smart digital expert for intralogistics.
